Lithium Ion Battery 51.8V 30Ah (2)

Empower your applications with our premium NMC (Nickel Manganese Cobalt) Lithium-Ion battery packs. Engineered for high energy density and long-term reliability, these batteries are housed in a rugged MS Metal Box cabinet, making them ideal for electric mobility and industrial power solutions.

Each unit is equipped with a comprehensive Hardware Battery Management System (BMS) to ensure peak safety and performance. With a lifespan of over 1,000 cycles at 90% Depth of Discharge (DOD), these batteries provide a dependable, long-term energy investment.

Technical Datasheet

Sr No	Parameters	Values
1	Chemistry	NMC
2	Nominal Voltage	51.8V
3	Capacity Ah	30Ah
4	Energy Density	1554 Wh
5	Charging Voltage	58.8V
6	Lower Cut Off Voltage	39.2V
7	Recommended Charging Current	6A
8	Max Discharging current	30A
9	Peak Discharge Current	40A
10	Charging Protocol	CC/CV
11	Cycle Life @ 90% DOD	>1000 cycles @ 25°C
12	Charging Tempertaure	0°C to 45°C
13	Discharging Temperature	-10°C to 60°C
14	Storage Temperature	0°C to 45°C
15	Cell Balancing	Yes
16	BMS Type	Hardware BMS
17	Smart BMS with Bluetooth	Optional
18	CAN Communication	Optional
19	Protections	Over Charge Voltage and current, Over discharge Voltage and current, Over Charge Temperature, Over Discharge Temperature, Short Circuit
20	Charging/Discharging Port	Separate
21	Charging Port Type	C14 3 Pin Male/3 Pin Round Female
22	Discharging Port Type	Anderson SB50
23	Battery Cabinet	MS Metal Box
24	Battery Weight	10 kgs approx
25	Dimensions (L x W x H)mm	(F) 160X235X190mm (Separate Port) (G) 220X180X170mm (Separate Port) (H) 185X205X200mm (Same Port) (I) 110X205X380mm (Same Port)
